50Hz Water Cooled Cummins Diesel Generator Set Supply1 1

50Hz Water Cooled Cummins Diesel Generator Set Supply1 2

50Hz Water Cooled Cummins Diesel Generator Set Supply1 3

50Hz Water Cooled Cummins Diesel Generator Set Supply1 4

50Hz Water Cooled Cummins Diesel Generator Set Supply1 5

50Hz Water Cooled Cummins Diesel Generator Set Supply1 6

50Hz Water Cooled Cummins Diesel Generator Set Supply1 7

50Hz Water Cooled Cummins Diesel Generator Set Supply1 8

50Hz Water Cooled Cummins Diesel Generator Set Supply1 9

50Hz Water Cooled Cummins Diesel Generator Set Supply1

Brand:

JET POWER

Factory Price:

Negotiate

Port:

FUZHOU, CHINA

Payment Terms:

L/C, Cash, Western Union, T/T

ODM & OEM:

Available

Certification:

ISO9001, CE

Inquiry

Write a Review

• Output:20kVA - 1650KVA
• Powered by Cummins
• Alternator: Stamford, Leroy Somer, Marathon, Jet Power, Mecc alte
• Open type / Silent type
• Product description: Cummins Diesel Generator Set Power from 20KVA to 1650KVA. optional: Open type, Silent type, Container type, trailer type.
• Optional: ATS system, AMF function, Parallel system.

PRODUCT DESCRIPTION

Silent diesel generator set, Powered by Cummins ENGINE

Soundproof diesel generator set

Safety – Stability – Economy - Reliability Power

01. Our cooperate with famous diesel engine –Powered by Cummins, Perkins, Deutz , LovoL , Lister Petter, Doosan, Yanmar, Kubota, Shangchai, SDEC, Weichai, MTU, Ricardo, Jichai.
02. Equipped with famous Brushless alternator – Optional Stamford, Leroy Somer,Marathon, JET Power, Mecc alte.
03. Equipped with50°Cradiator with fan, enough engine cooling system guarantee long time working
04. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen , ComAp , Jet Power
05. Generator set use High-quality steel are thickness canopy --2MM to 10MM
06. Equipped with high density sound-absorbing material -- sound insulation, fireproofing
07. Generator equipped with 12V/ 24V DC battery with charger, battery connects wire.
08. Generator equipped with 10-12 hours fuel tank with fuel indicator, long time for working.
09. High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker
10. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.
11. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance
12. Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator.
13. All new design for diesel generator set of Silent, Supper silent, Soundproof, Trailer type, Container type.

_________________________________________________________________________________________________________________________

50Hz Water Cooled Cummins Diesel Generator Set Supply1 10

DIESEL ENGINE

Powered by Cummins Engine, Perkins Engine, Deutz , LOVOL , Lister Petter , Doosan , Yanmar , Kubota, Shangchai, SDEC, Weichai, MTU, Ricardo, Jichai.
• Brand new engine 4-Strokes,Water cooled, direct injection engine
• Rated Speed: 1500rpm / 1800rpm
• Start type: 12V or 24V DC Electrical Start
• Governing control: Mechanical or Electrical
• Radiator standard: 50°environment temperature
• Altitude above sea level: ≤1000 meters
• Ambient air temperature: ≤40°C

50Hz Water Cooled Cummins Diesel Generator Set Supply1 11

A.C ALTERNATOR

Self-regulation is obtained through a digital electronic regulator that is fed by an auxiliary winding.The windings have a 2/3 pitch in order to reduce the harmonic content of voltage.
• Generator Phase and connecting: 3 phase, 4wire.
• Rated frequency: 50Hz@1500rpm / 60Hz@1800rpm.
• Alternator excited type: Brushless, self excited or PMG optional
• Alternator Insulation: Class H， Protection: IP21 ~ IP23
• Voltage regulation: AVR automatic control 1%
• Altitude above sea level: ≤1000 meters
• Ambient air temperature: ≤40°
• Relative air humidity: ≤ 90%
Complies with the most common specifications such as CEI 2-3, IEC 34-1, EN 60034-1, VDE 0530, BS 4999-5000, CAN/ CSA-C22.2 No14-95- No100-95.

Controller System

• DSE6020, HGM6120N, DSE7320 (AMF) Series Standard control panel, Optional Automatic transfer switch (ATS) and Automatic parallel operation system, Remote control system.

• Automatic transfer switch (ATS) and Automatic parallel operation system

Accessories

Standard accessories: Standard 50 radiator mounted on skid. Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wire, Standard tool kit, operation manual and Testing document

Manufacturing Standard

GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard ,GB755,BS 5000,VDE 0530, NEMA MG1-22,IEC34.

Product Warranty policy

JET Power product has guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, our will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material. After expiration, our provides cost spare parts maintenance of alternator. If engine with international warranty service, the engine product warranty by local authorization Service agent.

PRODUCT SPECIFICATIONS

Model	400V / 50Hz / 1500RPM				Cummins Diesel Engine 1500rpm				Fuel Consumption @ 100% Load	Alternator
	Standby output		Prime Output		Model	No. of Cylinder	Displacement	Bore×Stroke	Fuel Consumption @ 100% Load	Original Stamford
	KVA	KW	KVA	KW	Model	No. of Cylinder	(L)	(MM)	(L/H)	Original Stamford
C-22	22	18	20	16	4B3.9-G1	4L	3.9	102ˣ120	6.3	PI144D
C-28	28	22	25	20	4B3.9-G1	4L	3.9	102ˣ120	7.1	PI144E
C-33	33	26	30	24	4BT3.9-G1	4L	3.9	102ˣ120	8	PI144G
C-41	41	33	38	30	4BT3.9-G1	4L	3.9	102ˣ120	10	PI144J
C-55	55	44	50	40	4BTA3.9-G2	4L	3.9	102ˣ120	12.9	UCI224D
C-66	66	53	60	48	4BTA3.9-G11	4L	3.9	102ˣ120	16	UCI224E
C-80	80	64	73	58	4BTA3.9-G11	4L	3.9	102ˣ120	17.6	UCI224F
C-94	94	75	85	68	6BT5.9-G1	6L	5.9	102ˣ120	19	UCI224G
C-110	110	88	100	80	6BT5.9-G1	6L	5.9	102ˣ120	21.7	UCI274C
C-125	125	100	114	91	6BTA5.9-G2	6L	5.9	102ˣ120	27	UCI274D
C-143	143	114	130	104	6BTAA5.9-G2	6L	5.9	102ˣ120	30	UCI274E
C-165	165	132	150	120	6BTAA5.9-G12	6L	5.9	102ˣ120	34	UCI274F
C-176	176	141	160	128	6CTA8.3-G1	6L	8.3	114ˣ135	40	UCI274F
C-200	200	160	175	140	6CTA8.3-G1	6L	8.3	114ˣ135	42	UCI274G
C-220	220	176	200	160	6CTAA8.3-G2	6L	8.3	114ˣ135	45	UCI274H
C-250	250	200	225	180	6LTAA8.9-G2	6L	8.3	114ˣ135	53	UCDI274J
C-275	275	220	250	200	6LTAA8.9-G3	6L	8.3	114ˣ145	54	UCDI274K
C-275	275	220	250	200	MTA11-G2	6L	10.8	125ˣ147	52	UCDI274K
C-275	275	220	250	200	NT855-GA	6L	14	140ˣ152	53	UCDI274K
C-313	313	250	275	220	MTAA11-G3	6L	10.8	125ˣ147	59	HCI444D
C-344	344	275	313	250	MTAA11-G3	6L	10.8	125ˣ147	62	HCI444ES
C-350	350	280	313	250	NTA855-G1B	6L	14	140ˣ152	68	HCI444ES
C-385	385	308	350	280	NTA855-G2A	6L	14	140ˣ152	72	HCI444E
C-413	413	330	375	300	QSNT-G3	6L	14	140ˣ152	82	HCI444FS
C-413	413	330	375	300	NTAA855-G7	6L	14	140ˣ152	86	HCI444FS
C-440	440	352	400	320	QSNT-G3	6L	14	140ˣ152	86	HCI444F
C-440	440	352	400	320	6ZTAA13-G2	6L	13	130ˣ163	89.1	HCI444F
C-460	460	368	438	350	6ZTAA13-G4	6L	13	130ˣ163	91.4	HCI544C
C-500	500	400	450	360	QSZ13-G2	6L	13	130ˣ163	88.8	HCI544C
C-500	500	400	450	360	KTA19-G3	6L	18.9	159ˣ159	97	HCI544C
C-550	550	440	500	400	QSZ13-G3	6L	13	130ˣ163	101	HCI544D
C-550	550	440	500	400	KTA19-G4	6L	18.9	159ˣ159	107	HCI544D
C-633	633	506	575	460	KTAA19-G6	6L	18.9	159ˣ159	118	HCI544E
C-650	650	520	585	468	KTA19-G8	6L	18.9	159ˣ159	126	HCI544E
C-688	688	550	625	500	QSK19-G4	6L	18.9	159ˣ159	142	HCI544FS
C-715	715	572	650	520	QSK19-G4	6L	18.9	159ˣ159	145	HCI544F
C-800	800	640	725	580	KTA38-GA	12V	37.8	159ˣ159	225	LVI634B
C-825	825	660	750	600	KTA38-G2	12V	37.8	159ˣ159	167	LVI634B
C-880	880	704	800	640	KTA38-G2B	12V	37.8	159ˣ159	169	HCI634G
C-1000	1000	800	910	728	KTA38-G2A	12V	37.8	159ˣ159	191	HCI634H
C-1100	1100	880	1000	800	KTA38-G5	12V	37.8	159ˣ159	209	HCI634J
C-1250	1250	1000	1125	900	KTA38-G9	12V	37.8	159ˣ159	235	LVI634G
C-1375	1375	1100	1250	1000	QSKTA38-G5	12V	37.8	159ˣ159	274	LVI634G
C-1375	1375	1100	1250	1000	KTA50-G3	16V	50.3	159ˣ159	261	LVI634G
C-1540	1540	1232	1400	1120	KTA50-G8	16V	50.3	159ˣ159	289	PI734B
C-1650	1650	1320	1500	1200	KTA50-GS8	16V	50.3	159ˣ159	309	PI734C
